Model No.: GS13M435HF
Brand: Farizon
Applicable Industry: Manufacturing Plant, Machinery Repair Shops, Construction Works, Energy &Amp; Mining, Other, Advertising Company
Out-of-warranty Service: Online Support, Spare Parts
Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None
Showroom Location (in Which Countries Are There Sample Rooms Overseas): None
Old And New: New
Stroke: 4 Stroke
Number Of Cylinders: Multi-Cylinder
Cooling Method: Water-Cooled
Start Method: Electric Start
Place Of Origin: China
Warranty Period: 5 Years
Service System: Overseas Service Center Available
Displacement: 1.2l
Emission Standards: Epa Tier2
Mechanical Test Report: Provided
Video Factory Inspection: Provided
Marketing Type: New Product 2020
Core Component Warranty Period: 3 Months
Core Components: Gear, Engine, Pressure Vessel, Pump
Core Selling Point: Other
Power (Watts): 315 Kw
| Picture Example: |
|
|---|
Transportation: Ocean
Place of Origin: China
| Item | Unit | Engine set parameters |
| Type | - | In-line,four-stroke,liquid-cooled,supercharged and intercooled |
| Fuel type | - | Main fuel:M100 methanol Auxiliary starting fuel:92#gasoline No gasoline auxiliary starting device is used.and coolant heating is required to ensure engine starting |
| Number of cylinders-bore*stroke | mm | 6-130*161 |
| Compression ratio | - | 12.5:1 |
| Total piston displacement | L | 12.82 |
| Speed | rpm | 1500@50 |
| Engine quality | kg | 1180 |
| Generator set power | kW COP | kW PRP | kW LTP | kW ESP |
| 50Hz | 250kW | 250kW | 300kW | 300kW |
| Working conditions | Power | Fuel consumption |
| kW | kg/h | |
| 110%Spare | 352 | 154.13 |
| 100%Common | 320 | 139.01 |
| 80% | 256 | 111.96 |
| 50% | 160 | 74.71 |
| 30% | 96 | 51.72 |
