Low-Emission Methanol Power Engine for Clean Power
Low-Emission Methanol Power Engine for Clean Power
Low-Emission Methanol Power Engine for Clean Power
Low-Emission Methanol Power Engine for Clean Power
Low-Emission Methanol Power Engine for Clean Power

Low-Emission Methanol Power Engine for Clean Power

Get Latest Price
    Contact Now
    Share:
    • Min. Order: 1
    Description
    Product Attributes

    Model No.: GS13M435HF

    Packaging & Delivery
    Product Description
    The methanol non road GS13M series engine has fully switched to the second - generation Geely autonomous methanol control system, using M100 methanol Clean energy. It has comprehensive improved in efficient combustion, low - temperature starting, intelligent diagnosis, emission control, corrosion resistance, and wear resistance, creating excellent performance of this engine with high performance, low Fuel consumption, high reliability, and low emissions. Fully validated under application conditions such as Generator sets, ship engines, and construction machinery.
    High performance: adopting high compression ratio, high - energy ignition, high roll flow inlet structure, while optimizing the valve timing mechanism, adopting technologies such as intake turbocharging and intercooling to make combustion more complete and power more powerful.
    Low fuel consumption: optimizing combustion through the second - generation Geely autonomous methanol control system, the engine has better fuel economy, low operating cost, and extremely high cost - effectiveness, which can save 20% compared to Diesel Engines in terms of economy.
    High reliability: Adhere to the concept of high - quality development, from a technical perspective CAE analysis and experimental verification are considered from multiple dimensions to ensure reliable product quality and long service life, B10 has a lifespan of ≥ 1.2 million kilometers.
    Ultra low emissions: Methanol is recognized as a clean energy source. Compared to conventional fuels such as gasoline and diesel, methanol  combustion is more complete and thorough, and its emissions include CO HC and NOx emissions have significantly decreased, with almost no particulate emissions, and emissions have decreased by ≥ 85%.
    MEE933
    Engine performance parameters
    Item Unit Engine set parameters
    Type -
    In-line,four-stroke,liquid-cooled,supercharged and intercooled
    Fuel type -
    Main fuel:M100 methanol
    Auxiliary starting fuel:92#gasoline
    No gasoline auxiliary starting device is used.and coolant heating is required to ensure engine starting
    Number of cylinders-bore*stroke
    		 mm 6-130*161
    Compression ratio - 12.5:1
    Total piston displacement L 12.82
    Speed rpm 1500@50
    Engine quality kg 1180

    Generator set power kW COP kW PRP kW LTP kW ESP
    50Hz 250kW 250kW 300kW 300kW

    Working conditions Power Fuel consumption
      kW kg/h
    110%Spare 352 154.13
    100%Common 320 139.01
    80% 256 111.96
    50% 160 74.71
    30% 96 51.72
